Red Wire From Ceiling
To install a ceiling fan.
Red wire from ceiling. Samuel the red wire from the ceiling fan fixture box is typically connected to the blue wire of the ceiling fan which is for the light fixture of the ceiling fan. Check the wire with a non contact voltage tester with the power and. Turn off the power. Each of these has a black hot wire and each should also have a white neutral wire and a bare ground wire although there may be only one common neutral and one common ground to serve both circuits.
Ground wires are either left bare or covered with green insulation. Ceiling fixtures almost always have a black and white wire. If not color all phase 2 wires with. Normally youll see a red wire in places you would expect a ceiling fan.
Wiring diagrams for ceiling fans may be found using the links below. A red wire up in the ceiling fan junction box usually indicates that the wiring has been installed which provides separate switch for the light and a separate switch for the fan motor. In this case red is hot. An extra red wire in the electrical box is probably an extra hot wire for a fan.
In my friends case the solution was simple if not intuitive. The red wire is used on a ceiling fan installation when the wiring includes two wall switches in which case one switch operates the light and the other switch operates the fan. When there is an extra hot wire it is red. In rare instances the kit may include a red and yellow wire instead.
But in places like a bathroom or a wall light if you see a red wire its a good bet that the red wire is the wire thats connected to the light switch. Except in rare cases it is a hot wire or a switched hot wire. So the red wire is probably the one you want. Ceiling fan red wire connection.
A ceiling fan with a light fixture usually has two separate circuits one for the fan and one for the lights. If your ceiling fan does not have a light fixture then simply cap off the red wire and attach the fan motor to the black wire. When wiring a panel or installing breakers identify wire color to insure that when you are sharing the neutral the black is on phase 1 and red wire on phase 2.
